Products

HVAC Control Board WS()C Water Source Heat Pump

HVAC Furnace Control Board

HVAC Rectifier Board 24VDC

HVAC Air Handler Main Control Board

HVAC Main Control Board Assembly

HVAC Main Control Board Assembly

HVAC Indoor Control Board

HVAC Outdoor Control Board

HVAC Relay 24 VAC 50/60Hz SPDT

HVAC Time Delay Relay 0.03 - 10 Minute Make Time 18-230 VAC Current Rating - Inrush (A): 15 | Current Rating - Steady State (A): 1.50 | Electrical Connections: Stripped Wire Leads | Frequency (Hz): 50/60 | Make Time Delay (minutes): 0.03 - 10 | Make Time Delay (seconds): 1.5 - 600 | Time Delay Adjustment: Variable | Type: On Delay on Make | Voltage Rating (VAC): 18-230

HVAC Time Delay Relay - Delay On Break Timer Current Rating - Inrush (A): 15 | Current Rating - Steady State (A): 1.50 | Electrical Connections: Stripped Wire Leads | Frequency (Hz): 50/60 | Make Time Delay (minutes): 0.03 - 10 | Make Time Delay (seconds): 1.5 - 600 | Time Delay Adjustment: Variable | Type: On Delay on Brake | Voltage Rating (VAC): 18-240

HVAC Sequencing Relay 1-Pole SPST - NO (Normally Open) Heater 24 VAC / 0.2A Steady State / 0.9A Maximum Connections: 1/4 inch quick connects | Contact configuration: SPST - NO | Heater voltage (V): 24 | Heater wattage/ power consumption: 24 VAC / 0.2A steady state / 0.9A maximum | Motor FLA at 120V (A): Pole 1: 14 | Motor FLA at 230V (A): Pole 1: 7 | Motor FLA at 460V (A): Pole 1: 3 | Motor LRA at 120V (A): Pole 1: 72 | Motor LRA at 230V (A): Pole 1: 42 | Motor LRA at 460V (A): Pole 1: 18 | Mounting: Angle bracket w/two mounting holes | Number of poles: 1 | Off timing - Pole 1 (seconds): 40-90 | On timing - Pole 1 (seconds): 1-30 | Pilot duty rating at 120V (VA): Pole 1: 125 | Pilot duty rating at 230V (VA): Pole 1: 125 | Pilot duty rating at 460V (VA): Pole 1: 125 | Resistive rating at 120V (A): Pole 1: 25 | Resistive rating at 230V (A): Pole 1: 25 | Resistive rating at 460V (A): Pole 1: 12.5

HVAC Sequencing Relay 3-Pole TPST - NO (Normally Open) Heater 24 VAC / 0.2A Steady State / 0.55A Maximum Connections: 1/4 inch quick connects | Contact configuration: TPST - NO | Heater voltage (V): 24 | Heater wattage/ power consumption: 24 VAC / 0.2A steady state / 0.55A maximum | Motor FLA at 120V (A): Pole 1: 7 Pole 2: 7 Pole 3: 7 | Motor FLA at 230V (A): Pole 1: 7 Pole 2: 7 Pole 3: 7 | Motor FLA at 460V (A): Pole 1: 3 Pole 2: 3 Pole 3: 3 | Motor LRA at 120V (A): Pole 1: 42 Pole 2: 42 Pole 3: 42 | Motor LRA at 230V (A): Pole 1: 42 Pole 2: 42 Pole 3: 42 | Motor LRA at 460V (A): Pole 1: 18 Pole 2: 18 Pole 3: 18 | Mounting: Angle bracket w/two mounting holes | Number of poles: 3 | Off timing - Pole 1 (seconds): 30-60 | Off timing - Pole 2 (seconds): 30-60 | Off timing - Pole 3 (seconds) 30-60 | On timing - Pole 1 (seconds) 10-30 | On timing - Pole 2 (seconds): 10-30 | On timing - Pole 3 (seconds): 10-30 | Pilot duty rating at 120V (VA): Pole 1: 125 Pole 2: 125 Pole 3: 125 | Pilot duty rating at 230V (VA): Pole 1: 125 Pole 2: 125 Pole 3: 125 | Pilot duty rating at 460V (VA): Pole 1: 125 Pole 2: 125 Pole 3: 125 | Resistive rating at 120V (A): Pole 1: 25 Pole 2: 25 Pole 3: 25 | Resistive rating at 230V (A): Pole 1: 25 Pole 2: 25 Pole 3: 25 | Resistive rating at 460V (A): Pole 1: 12.5 Pole 2: 12.5 Pole 3: 12.5

HVAC Sequencing Relay 2-Pole DPST - NO (Normally Open) Heater 24 VAC / 0.2A Steady State / 0.55A Maximum Connections: 1/4 inch quick connects | Contact configuration: DPST - NO | Heater voltage (V): 24 | Heater wattage/ power consumption: 24 VAC / 0.2A steady state / 0.55A maximum | Motor FLA at 120V (A): Pole 1: 14 Pole 2: 14 | Motor FLA at 230V (A): Pole 1: 7 Pole 2: 7 | Motor FLA at 460V (A): Pole 1: 3 Pole 2: 3 | Motor LRA at 120V (A): Pole 1: 72 Pole 2: 72 | Motor LRA at 230V (A): Pole 1: 42 Pole 2: 42 | Motor LRA at 460V (A): Pole 1: 18 Pole 2: 18 | Mounting: Angle bracket w/two mounting holes | Number of poles: 2 | Off timing - Pole 1 (seconds): 90-160 | Off timing - Pole 2 (seconds): 30-60 | On timing - Pole 1 (seconds): 10-40 | On timing - Pole 2 (seconds): 30-60 | Pilot duty rating at 120V (VA): Pole 1: 125 Pole 2: 125 | Pilot duty rating at 230V (VA): Pole 1: 125 Pole 2: 125 | Pilot duty rating at 460V (VA): Pole 1: 125 Pole 2: 125 | Resistive rating at 120V (A): Pole 1: 25 Pole 2: 25 | Resistive rating at 230V (A): Pole 1: 25 Pole 2: 25 | Resistive rating at 460V (A): Pole 1: 12.5 Pole 2: 12.5

HVAC Sequencing Relay 3-Pole TPST - NO (Normally Open) Heater 24 VAC / 0.2A Steady State / 0.55A Maximum Connections: 1/4 inch quick connects | Contact configuration: TPST - NO | Heater voltage (V): 24 | Heater wattage/ power consumption: 24 VAC / 0.2A steady state / 0.55A maximum | Motor FLA at 120V (A): Pole 1: 7 Pole 2: 7 Pole 3: 7 | Motor FLA at 230V (A): Pole 1: 7 Pole 2: 7 Pole 3: 7 | Motor FLA at 460V (A): Pole 1: 3 Pole 2: 3 Pole 3: 3 | Motor LRA at 120V (A): Pole 1: 42 Pole 2: 42 Pole 3: 42 | Motor LRA at 230V (A): Pole 1: 42 Pole 2: 42 Pole 3: 42 | Motor LRA at 460V (A): Pole 1: 18 Pole 2: 18 Pole 3: 18 | Mounting: Angle bracket w/two mounting holes | Number of poles: 3 | Off timing - Pole 1 (seconds): 90-150 | Off timing - Pole 2 (seconds): 30-60 | Off timing - Pole 3 (seconds): 30-60 | On timing - Pole 1 (seconds): 10-30 | On timing - Pole 2 (seconds): 10-30 | On timing - Pole 3 (seconds): 10-30 | Pilot duty rating at 120V (VA): Pole 1: 125 Pole 2: 125 Pole 3: 125 | Pilot duty rating at 230V (VA): Pole 1: 125 Pole 2: 125 Pole 3: 125 | Pilot duty rating at 460V (VA): Pole 1: 125 Pole 2: 125 Pole 3: 125 | Resistive rating at 120V (A): Pole 1: 25 Pole 2: 25 Pole 3: 25 | Resistive rating at 230V (A): Pole 1: 25 Pole 2: 25 Pole 3: 25 | Resistive rating at 460V (A): Pole 1: 12.5 Pole 2: 12.5 Pole 3: 12.5

HVAC Sequencing Relay 2-Pole DPST - NO (Normally Open) Heater 24 VAC / 0.2A Steady State / 0.55A Maximum Connections: 1/4 inch quick connects | Contact configuration: DPST - NO | Heater voltage (V) 24 | Heater wattage/ power consumption: 24 VAC / 0.2A steady state / 0.55A maximum | Motor FLA at 120V (A): Pole 1: 14 Pole 2: 14 | Motor FLA at 230V (A): Pole 1: 7 Pole 2: 7 | Motor FLA at 460V (A): Pole 1: 3 Pole 2: 3 | Motor LRA at 120V (A): Pole 1: 72 Pole 2: 72 | Motor LRA at 230V (A): Pole 1: 42 Pole 2: 42 | Motor LRA at 460V (A): Pole 1: 18 Pole 2: 18 | Mounting: Angle bracket w/two mounting holes | Number of poles: 2 | Off timing - Pole 1 (seconds): 30-60 | Off timing - Pole 2 (seconds): 30-60 | On timing - Pole 1 (seconds): 10-30 | On timing - Pole 2 (seconds): 10-30 | Pilot duty rating at 120V (VA): Pole 1: 125 Pole 2: 125 | Pilot duty rating at 230V (VA): Pole 1: 125 Pole 2: 125 | Pilot duty rating at 460V (VA): Pole 1: 125 Pole 2: 125 | Resistive rating at 120V (A): Pole 1: 25 Pole 2: 25 | Resistive rating at 230V (A): Pole 1: 25 Pole 2: 25 | Resistive rating at 460V (A): Pole 1: 12.5 Pole 2: 12.5

HVAC Start Relay 332 Max Voltage 40-90 Dropout V Cold pickup (V): 162-175 | Dropout (V): 40-90 | Frequency (Hz): 60 | Hot pickup (V): 170-180 | Maximum continuous coil voltage (V): 332

HVAC Sequencing Relay 2-Pole DPST - NO (Normally Open) Combination rating at 230V (RES/FLA/LRA): 30A Max: 23A resistive & 7A FL | Connections: 1/4 inch quick connects | Contact configuration: DPST - NO | Heater voltage (V): 24 | Heater wattage/ power consumption: 24 VAC/.10A -.18A steady state/.35 - 1.0 amps peak for 0.8 sec. | Motor FLA at 120V (A): Pole 1: 14 Pole 2: 14 | Motor FLA at 230V (A): Pole 1: 7 Pole 2: 7 | Motor FLA at 460V (A): Pole 1: 4 Pole 2: 4 | Motor LRA at 120V (A): Pole 1: 72 Pole 2: 72 | Motor LRA at 230V (A): Pole 1: 42 Pole 2: 42 | Motor LRA at 460V (A): Pole 1: 24 Pole 2: 24 | Mounting: Flush mount plate w/mounting hole & tab | Number of poles: 2 | Off timing - Pole 1 (seconds): 1-30 | Off timing - Pole 2 (seconds): 1-30 | On timing - Pole 1 (seconds): 30-60 | On timing - Pole 2 (seconds): 30-60 | Pilot duty rating at 120V (VA): Pole 1: 125 Pole 2: 125 | Pilot duty rating at 230V (VA): Pole 1: 125 Pole 2: 125 | Pilot duty rating at 460V (VA): Pole 1: 125 Pole 2: 125 | Resistive rating at 120V (A): Pole 1: 25 Pole 2: 25 | Resistive rating at 230V (A): Pole 1: 25 Pole 2: 25 | Resistive rating at 460V (A): Pole 1: 12.5 Pole 2: 12.5

HVAC Fan Relay 1PNO (Normally Open)/1PNC (Normally Closed) Control Voltage 24 VAC

HVAC Time Delay Relay Power Pole 7 FLA, 36 RLA @ 240VAC Pilot Pole 25 VA @ 24 VAC
