Supplying Demand SDD1036 D1036 HVAC Direct Drive Blower Motor 208-230V 1075 RPM 1/3 HP Phase: Single | Motor Design: Permanent Split Capacitor | HP: 1/3 | RPM: 1,075 | Number of Speeds: 3 | Voltage: 208-230V AC | Full Load Amps: 2.1 A | Frame: 48 | Usable @ 208V: Yes | Usable @ 200V: No | Motor Thermal Protection: Auto | Hz: 60 Hz | Ins. Class: B | Motor Shaft Rotation: CW/CCW | Max. Ambient Temperature: 40 °C | Lead Length: 26 in | Motor Enclosure Design: Open Air-Over | Motor Mounting Type: Ring | Motor Mounting Position: Horizontal | Number of Shafts: 1 | Motor Frame Material: Steel | Shaft Diameter: 1/2 in | Shaft Length: 4-1/2 in | Motor Bearings: Sleeve | Motor Shaft Design: Flat | Overall Length: 9-3/8 in | Length Less Shaft: 5-3/8 in | Mounting Holes: (4) #8-32 | Body Diameter: 5-5/8 in | Bolt Circle Diameter: 5-1/8 in | Stud Size: #8-32 | Ring to Ring Center: 4-15/16 in | Resilient Ring Diameter: 2-1/4 in | Capacitor Required: 2MDV4

Supplying Demand SDD1056 D1056 HVAC Direct Drive Blower Motor 208-230V 1075 RPM 1/2 HP Phase: Single | Motor Design: Permanent Split Capacitor | HP: 1/2 | RPM: 1,075 | Number of Speeds: 3 | Voltage: 208-230V AC | Full Load Amps: 3.6 A | Frame: 48 | Usable @ 208V: Yes | Usable @ 200V: No | Motor Thermal Protection: Auto | Hz: 60 Hz | Ins. Class: B | Motor Shaft Rotation: CW/CCW | Max. Ambient Temperature: 40 °C | Lead Length: 26 in | Motor Enclosure Design: Open Air-Over | Motor Mounting Type: Ring | Motor Mounting Position: Horizontal | Number of Shafts: 1 | Motor Frame Material: Steel | Shaft Diameter: 1/2 in | Shaft Length: 4-1/2 in | Motor Bearings: Sleeve | Motor Shaft Design: Flat | Overall Length: 9-7/8 in | Length Less Shaft: 5-7/8 in | Mounting Holes: (4) #8-32 | Body Diameter: 5-5/8 in | Bolt Circle Diameter: 5-1/8 in | Stud Size: #8-32 | Ring to Ring Center: 5-7/16 in | Resilient Ring Diameter: 2-1/4 in | Capacitor Required: 2MDV6

Supplying Demand SDD1076 D1076 HVAC Direct Drive Blower Motor 208-230V 1075 RPM 3/4 HP

Supplying Demand SDFD6000A FD6000A HVAC Direct Drive Blower Motor 208-230V 1075 RPM 1/2 to 1/6 HP

Supplying Demand SD6203E 6203E HVAC Direct Drive Blower Motor 208-230V 1075 RPM 1/3 HP

Supplying Demand SD6205E 6205E HVAC Direct Drive Blower Motor 208-230V 1075 RPM 1/2 HP

Supplying Demand SD6207E 6207E HVAC Direct Drive Blower Motor 208-230V 1075 RPM 3/4 HP

Supplying Demand SD6210E 6210E HVAC Direct Drive Blower Motor 208-230V 1075 RPM 1 HP

Supplying Demand SD6005E 6005E HVAC Direct Drive Blower Motor 115/230V 1075 RPM 1/2 - 1/5 HP Phase: Single | Motor Design: ECM | HP: 1/2 - 1/5 | RPM: 1,075 | Number of Speeds: 1 | Voltage: 115/230V | Current: 6.7/4.0 A | Frame: 48 | Motor Thermal Protection: None | Hz: 60 Hz | Ins. Class: B | Max. Ambient Temperature: 40 °C | Lead Length: 42 in | Motor Enclosure Design: Open Air-Over | Motor Mounting Type: Belly Band Mount | Shaft Diameter: 1/2 in | Motor Bearings: Ball | Motor Shaft Design: Flat | Body Diameter: 5.6 in.

Supplying Demand SD6010E 6010E HVAC Direct Drive Blower Motor 115/230V 1075 RPM 1 - 1/2 HP Phase: Single | Motor Design: ECM | HP: 1 - 1/2 | RPM: 1,075 | Number of Speeds: 1 | Voltage: 115/230V | Current: 11.0/6.7 A | Frame: 48 | Motor Thermal Protection: None | Hz: 60 Hz | Ins. Class: B | Max. Ambient Temperature: 40 °C | Lead Length: 42 in | Motor Enclosure Design: Open Air-Over | Motor Mounting Type: Belly Band Mount | Shaft Diameter: 1/2 in | Motor Bearings: Ball | Motor Shaft Design: Flat | Body Diameter: 5.6 in.

Supplying Demand SD6505V 6505V HVAC Direct Drive Blower Motor 120/240V 1050 RPM 1/2 HP

Supplying Demand SD6507V 6507V HVAC Direct Drive Blower Motor 120/240V 1050 RPM 3/4 HP

Supplying Demand SDTP-EC13-75 TP-EC13-75 HVAC Blower Motor 115/208-230V 1075 RPM 3/4 HP

Supplying Demand SD5862 5862 HVAC Direct Drive Blower Motor 115/208-230V 1075 RPM 1/2-1/3 HP Phase: 1 | Motor Type: ECM | HP: 1/2-1/3 | RPM: 1,075 | Number of Speeds: Variable | Voltage: 115/208-230V | Amps: 6.4/4.0-3.8 A | Insulation Class: B | Frame: 48 | Motor Thermal Protection: Electronically Protected | Hz: 60 Hz | Motor Shaft Rotation: CW/CCW | Max. Ambient Temperature: 40 °C | Motor Enclosure Design: Open Air-Over | Motor Mounting Type: Belly Band | Shaft Diameter: 1/2 in | Shaft Length: 5 in | Motor Bearings: Ball.

Supplying Demand SD5860 5860 HVAC Blower Motor 115/208-230V 1075 RPM 1-1/3HP Phase: 1 | Motor Type: ECM | HP: 1-1/3 | RPM: 1,075 | Number of Speeds: Variable | Voltage: 115/208-230V | Amps: 7.1-12.1 A | Insulation Class: B | Frame: 48 | Motor Thermal Protection: Electronically Protected | Hz: 60 Hz | Motor Shaft Rotation: CW/CCW | Max. Ambient Temperature: 40 °C | Motor Enclosure Design: Open Air-Over | Motor Mounting Type: Belly Band | Shaft Diameter: 1/2 in | Shaft Length: 5 in | Motor Bearings: Ball.

Supplying Demand SD5861 5861 HVAC Blower Motor 115/208-230V 1075 RPM 3/4-1/3 HP Phase 1 Motor Type ECM HP 3/4-1/3 RPM 1,075 Number of Speeds Variable Voltage 115/208-230V Amps 5.5-9.3 A Insulation Class B Frame 48 Motor Thermal Protection Electronically Protected Hz 60 Hz Motor Shaft Rotation CW CCW Max Ambient Temperature 40 °C Motor Enclosure Design Open Air Over Motor Mounting Type Belly Band Shaft Diameter 1/2 in Shaft Length 5 in Motor Bearings Ball

Supplying Demand SD51-104337-00 HVAC Control Module X-13/ENDURA PRO 230 Volt 1/3 HP Blank
