Products

HVAC Control Module X-13/ENDURA PRO 230 Volt 3/4 HP Blank Monitors the functions of an Endura Pro X-13 Motor while in operation. If the module detects functions operating outside normal parameters, it will shut down the system to protect the motor.

Supplying Demand 51-104671-01 HVAC Blower Motor - 1/2 HP, 1 Phase, 4 Speed, 120V, 1075 RPM

HVAC Module - SelecTech Gen 2 230V - 3/4 HP - BLANK Blank replacement module for 3/4 HP 230V SelecTech motor series 51-104360-xx. This module can ONLY be used for Gen 2 SelecTech motors, NOT Gen 3 motors. This module is sold “unprogrammed” only. You will need a PROTECH Motor Programming kit PD510011 and U.S. Motors module KIT41 to program and use this part.

HVAC Control Module - Eon (ECM) - 1/2 HP - Blank

HVAC Blower Motor 3/4 HP 3 Phase 1 Speed, 208/230/460V 1725 RPM Application: Blower | Bearing Type: Ball | Drive Type: Belt Drive | FLA at 208V (A): 3.40 | FLA at 230V (A): 3.20 | FLA at 460V (A): 1.60 | Frame Size: 56 | Frequency (Hz): 60 | High Speed (RPM): 1725 | HP: 3/4 | Input Voltage (V): 208 / 230 / 460 | Keyed/Flat Shaft Length (in.): 3/16 x 3/16 x 1-5/8 | LRA at 230V (A): 14.60 | LRA at 460V (A): 7.30 | Motor Body Diameter (in.): 5-5/8 | Motor Body: Length (in.): 8-7/8 | Mounting: Platform | Number of Phases: 3 | Number of Speeds: 1 | Overall Motor Length (in.): 10-3/4 | Overall Shaft Length (in.): 1-7/8 | Rotation Direction (OSE): Reversible | Shaft Diameter (in.): 5/8

HVAC Vent Motor with Blades 208/230V motor with nominal 3000 rpm | Includes centrifugal proving switch | Mounting bolt pattern 4-1/4 inch x 4-1/4 inch | Includes three fan blades (3 inch, 3-1/2 inch, and 4 inch diameter)

HVAC Blower Motor 1/2 HP 1 Phase 3 Speed 120V 1075 RPM Application: Blower | Bearing Type: Sleeve | Drive Type: Direct Drive | FLA at 120V (A): 5.80 | Frame Size: 48 | Frequency (Hz): 60 | High Speed (RPM): 1075 | HP: 1/2 | Input Voltage (V): 120 | Keyed/Flat Shaft Length (in.): 3 | LRA at 120V (A): 12.40 | Motor Body Diameter (in.): 5-5/8 | Motor Body Length (in.): 4-3/4 | Mounting: Shell-band / Shell-screw | Number of Phases: 1 | Number of Speeds: 3 | Overall Motor Length (in.): 8-1/4 | Overall Shaft Length (in.): 3-1/2 | Rotation Direction (OSE): CCW | Run Capacitor (uF/V): 7.5/370 | Shaft Diameter (in.): 1/2

HVAC Blower Motor 1/6 - 1/2 HP 1 Phase 4 Speed 120V 1075 RPM Application: Blower | Bearing Type: Sleeve | Drive Type: Direct Drive | FLA at 120V (A): 7.30 | Frame Size: 48 | Frequency (Hz): 60 | High Speed (RPM): 1075 | HP: 1/6 to 1/2 | Input Voltage (V): 120 | Keyed/Flat Shaft Length (in.): 4 | Motor Body Diameter (in.): 5-5/8 | Motor Body Length (in.): 4-11/16 | Mounting: Shell-band / Shell-screw / Thru-bolt | Number of Phases: 1 | Number of Speeds: 4 | Overall Motor Length (in.): 9-11/16 | Overall Shaft Length (in.): 5 | Rotation Direction (OSE): Reversible | Run Capacitor (uF/V): 5/370, 7.5/370, or 10/370 | Shaft Diameter (in.): 1/2

HVAC Blower Motor 1/4 - 3/4 HP 1 Phase 4 Speed 120V 1075 RPM Application: Blower | Bearing Type: Ball | Drive Type: Direct Drive | FLA at 120V (A): 9.50 | Frame Size: 48 | Frequency (Hz): 60 | High Speed (RPM): 1075 | HP: 1/4 to 3/4 | Input Voltage (V): 120 | Keyed/Flat Shaft Length (in.): 4 | Motor Body Diameter (in.): 5-5/8 | Motor Body Length (in.): 5-13/16 | Mounting: Shell-band / Shell-screw | Number of Phases: 1 | Number of Speeds: 4 | Overall Motor Length (in.): 10-13/16 | Overall Shaft Length (in.): 5 | Rotation Direction (OSE): Reversible | Run Capacitor (uF/V): 10/370, 12.5/370, or 15/370 | Shaft Diameter (in.): 1/2

HVAC Blower Motor 1/6 - 1/2 HP 1 Phase 4 Speed 208/230V 1075 RPM Application: Blower | Bearing Type: Sleeve | Drive Type: Direct Drive | FLA at 230V (A): 3.60 | Frame Size: 48 | Frequency (Hz): 60 | High Speed (RPM): 1075 | HP: 1/6 to 1/2 | Input Voltage (V): 208 / 230 | Keyed/Flat Shaft Length (in.): 4 | LRA at 230V (A): 6.40 | Motor Body Diameter (in.): 5-5/8 | Motor Body Length (in.): 4-5/8 | Mounting: Shell-band / Thru-bolt | Number of Phases: 1 | Number of Speeds: 4 | Overall Motor Length (in.): 9-5/8 | Overall Shaft Length (in.): 5 | Rotation Direction (OSE): Reversible | Run Capacitor (uF/V): 5/370, 7.5/370, or 10/370 | Shaft Diameter (in.): 1/2

HVAC Blower Motor 1/4 HP 1 Phase 3 Speed 208/230V 1075 RPM Application: Blower | Bearing Type: Sleeve | Drive Type: Direct Drive | FLA at 230V (A): 2.00 | Frame Size: 48 | Frequency (Hz): 60 | High Speed (RPM): 1075 | HP: 1/4 | Input Voltage (V): 208 / 230 | Keyed/Flat Shaft Length (in.): 4 | LRA at 230V (A): 3.51 | Motor Body Diameter (in.): 5-5/8 | Motor Body Length (in.): 4-1/4 | Mounting: Shell-band / Thru-bolt | Number of Phases: 1 | Number of Speeds: 3 | Overall Motor Length (in.): 9-1/4 | Overall Shaft Length (in.): 5 | Rotation Direction (OSE): Reversible | Run Capacitor (uF/V): 5/370 | Shaft Diameter (in.): 1/2

Supplying Demand 51-23055-11 HVAC Condenser Motor 1/5 HP 1 Phase 1 Speed 208/230V 1075 RPM

HVAC Blower Motor 1/8 HP 1 Phase 2 Speed 208/220/230V 825 RPM Application: Blower | Bearing Type: Sleeve | Drive Type: Direct Drive | FLA at 230V (A): 1.40 | Frame Size: 48 | Frequency (Hz): 50 / 60 | High Speed (RPM): 825 | HP: 1/8 | Input Voltage (V): 208 / 220 / 230 | Keyed/Flat Shaft Length (in.): 1-1/2 | LRA at 230V (A): 1.80 | Motor Body Diameter (in.): 5-5/8 | Motor Body Length (in.): 4-1/4 | Mounting: Shell-band / Shell-screw | Number of Phases: 1 | Number of Speeds: 2 | Overall Motor Length (in.): 6-3/4 | Overall Shaft Length (in.): 2-9/16 | Rotation Direction (OSE): CCW | Run Capacitor (uF/V): 5/370 | Shaft Diameter (in.): 1/2

HVAC Blower Motor 1/2 HP 1 Phase 3 Speed 208/230V 1075 RPM This motor is for use in 60 Hz applications and is not to be used where a 50 Hz motor is required. No alternate is available for 50 Hz applications. Application: Blower | Bearing Type: Sleeve | Drive Type: Direct Drive | FLA at 230V (A): 2.40 | Frame Size: 48 | Frequency (Hz): 60 | High Speed (RPM): 1075 | HP: 1/2 | Input Voltage (V): 208 / 230 | Keyed/Flat Shaft Length (in.): 2-1/2 | LRA at 230V (A): 5.10 | Motor Body Diameter (in.): 5-5/8 | Motor Body Length (in.): 4-1/2 | Mounting: Shell-band | Number of Phases: 1 | Number of Speeds: 3 | Overall Motor Length (in.): 7-9/16 | Overall Shaft Length (in.): 3 | Rotation Direction (OSE): CCW | Run Capacitor (uF/V): 10/370 | Shaft Diameter (in.): 1/2

HVAC Blower Motor 3/4 HP 1 Phase 3 Speed 208/230V 1075 RPM Application: Blower | Bearing Type: Sleeve | Drive Type: Direct Drive | FLA at 230V (A): 4.40 | Frame Size: 48 | Frequency (Hz): 60 | High Speed (RPM): 1075 | HP: 3/4 | Input Voltage (V): 208 / 230 | Keyed/Flat Shaft Length (in.): 2-1/2 | LRA at 230V (A): 9.50 | Motor Body Diameter (in.): 5-5/8 | Motor Body Length (in.): 5-3/4 | Mounting: Shell-band | Number of Phases: 1 | Number of Speeds: 3 | Overall Motor Length (in.): 8-13/16 | Overall Shaft Length (in.): 3 | Rotation Direction (OSE): CCW | Run Capacitor (uF/V): 10/440 | Shaft Diameter (in.): 1/2

HVAC Blower Motor 1/2 HP 1 Phase 3 Speed 208/230V 1075 RPM Application: Blower | Bearing Type: Sleeve | Drive Type: Direct Drive | FLA at 230V (A): 2.70 | Frame Size: 48 | Frequency (Hz): 60 | High Speed (RPM): 1075 | HP: 1/2 | Input Voltage (V): 208 / 230 | Keyed/Flat Shaft Length (in.): 2-1/2 | LRA at 230V (A): 6.50 | Motor Body Diameter (in.): 5-5/8 | Motor Body Length (in.): 5-1/4 | Mounting: Shell-band | Number of Phases: 1 | Number of Speeds: 3 | Overall Motor Length (in.): 8-5/8 | Overall Shaft Length (in.): 2-1/2 | Rotation Direction (OSE): CW | Run Capacitor (uF/V): 10/370 | Shaft Diameter (in.): 1/2

HVAC Blower Motor 1/2 HP 1 Phase 4 Speed 120V 1075 RPM Application: Blower | Bearing Type: Sleeve | Drive Type: Direct Drive | FLA at 120V (A): 7.10 | Frame Size: 48 | Frequency (Hz): 60 | High Speed (RPM): 1075 | HP: 1/2 | Input Voltage (V): 120 | Keyed/Flat Shaft Length (in.): 3 | LRA at 120V (A): 12.40 | Motor Body Diameter (in.): 5-5/8 | Motor Body Length (in.): 4-3/4 | Mounting: Shell-band / Shell-screw | Number of Phases: 1 | Number of Speeds: 4 | Overall Motor Length (in.): 8-5/16 | Overall Shaft Length (in.): 3-1/2 | Rotation Direction (OSE): CCW | Run Capacitor (uF/V): 7.5/370 | Shaft Diameter (in.): 1/2

HVAC Blower Motor 1/2 HP 1 Phase 3 Speed 120V 1075 RPM Application: Blower | Bearing Type: Sleeve | Drive Type: Direct Drive | FLA at 120V (A): 7.90 | Frame Size: 48 | Frequency (Hz): 60 | High Speed (RPM): 1075 | HP: 1/2 | Input Voltage (V): 120 | Keyed/Flat Shaft Length (in.): 3 | LRA at 120V (A): 15.00 | Motor Body Diameter (in.): 5-5/8 | Motor Body Length (in.): 5-1/4 | Mounting: Shell-band / Shell-screw | Number of Phases: 1 | Number of Speeds: 3 | Overall Motor Length (in.): 9-1/16 | Overall Shaft Length (in.): 3-3/4 | Rotation Direction (OSE): CCW | Run Capacitor (uF/V): 15/370 | Shaft Diameter (in.): 1/2

HVAC Blower Motor 3/4 HP 1 Phase 4 Speed 120V 1075 RPM Application: Blower | Bearing Type: Sleeve | Drive Type: Direct Drive | FLA at 120V (A): 9.50 | Frame Size: 48 | Frequency (Hz): 60 | High Speed (RPM): 1075 | HP: 3/4 | Input Voltage (V): 120 | Keyed/Flat Shaft Length (in.): 3-1/16 | LRA at 120V (A): 23.00 | Motor Body Diameter (in.): 5-5/8 | Motor Body Length (in.): 5-13/16 | Mounting: Shell-band / Shell-screw | Number of Phases: 1 | Number of Speeds: 4 | Overall Motor Length (in.): 9-9/16 | Overall Shaft Length (in.): 3-3/4 | Rotation Direction (OSE): CCW | Run Capacitor (uF/V): 15/370 | Shaft Diameter (in.): 1/2

HVAC Blower Motor 1/4 HP 1 Phase 2 Speed 208/220/230V 825 RPM Application: Blower | Bearing Type: Sleeve | Drive Type: Direct Drive | FLA at 230V (A): 2.10 | Frame Size: 48 | Frequency (Hz): 50 / 60 | High Speed (RPM): 825 | HP: 1/4 | Input Voltage (V): 208 / 220 / 230 | Keyed/Flat Shaft Length (in.): 1-1/2 | LRA at 230V (A): 3.10 | Motor Body Diameter (in.): 5-5/8 | Motor Body Length (in.): 4-1/2 | Mounting: Shell-band / Shell-screw | Number of Phases: 1 | Number of Speeds: 2 | Overall Motor Length (in.): 7-13/16 | Overall Shaft Length (in.): 3-5/16 | Rotation Direction (OSE): CCW | Run Capacitor (uF/V): 10/370 | Shaft Diameter (in.): 1/2
