HVAC Run Capacitor 25/440R 25 MFD 440 Volt Round

HVAC Run Capacitor 70/440R 70 MFD 440 Volt Round

HVAC Ignitor Direct Spark Ignition DSI - For use with gas-fired unit heaters

HVAC Thermocouple 24-Inch Temperature ratings (C): Hot junction 760 C / Cold junction 416 C | Temperature ratings (F): Hot junction 1400 F / Cold junction 780 F | Voltage: 30 mV / Open circuit output 26 mV to 32 mV | Connection type: 11/32 32 Male connector nut | Resistance: 0.02 ohms | Length (in.): 24 | Length (mm): 610

HVAC Thermocouple 30-Inch Temperature ratings (C): Hot junction 760 C / Cold junction 416 C | Temperature ratings (F): Hot junction 1400 F / Cold junction 780 F | Voltage: 30 mV / Open circuit output 26 mV to 32 mV | Connection type: 11/32 32 Male connector nut | Resistance: 0.02 ohms | Length (in.): 30 | Length (mm): 762

HVAC Thermocouple 36-Inch Temperature ratings (C): Hot junction 760 C / Cold junction 416 C | Temperature ratings (F): Hot junction 1400 F / Cold junction 780 F | Voltage: 30 mV / Open circuit output 26 mV to 32 mV | Connection type: 11/32 32 Male connector nut | Resistance: 0.02 ohms | Length (in.): 36 | Length (mm): 914

HVAC Furnace Ignitor 208/230V

HVAC Thermocouple 30-Inch Length (Inches): 30 | Connection type: 11/32" 32 Male nut | Temperature rating: 1450°F Max | Voltage: 30mV

Universal Hot Surface Ignition Integrated Furnace Control Frequency: 60 Hz | Operating humidity range (% RH): 0% to 95% non-condensing | Operating temperature range (F): -40 F to +175 F | Operating temperature range (C): -40 C to +79 C | Flame failure response time (sec): 2 Seconds max @ 1µA | PrePurge: 30 seconds | PostPurge: 15 seconds | Cool fan on delay: 5 seconds | Cool fan off delay: 0 or 60 seconds | Line voltage: 120 Vac (97-132 Vac) | Low voltage: 24V (18-30 Vac) | Igniter current: 5 A resistive @ 120VAC | Thermostat anticipator setting: (Stage 1 only) 100mA | HSI Warmup time: 17/27 or 30/30 seconds | Trial for ignition: 4, 6, or 8 seconds | Interpurge: 60 seconds | Ignition trials: Three, two retries if flame is not sensed | Number of LEDs: 3 | Heat on fan delay: 30 or 60 seconds | Heat off fan delay: 60, 90, 120, or 180 Seconds | Gas control used with: Any 24Vac redundant, direct ignition gas control rated at 1.5A or less. Honeywell VR8205 recommended | Cooling contactor used with: Any 24Vac contactor rated at 1.0A or less | Induced draft blower load: 2.2FLA / 25LRA max @120Vac | Circulator load: 14.5FLA / 25LRA max @120Vac | Type of fan used with: Standard induction-type circulating fan

HVAC Intermittent Pilot Ignition Retrofit Kit Converts atmospheric standing pilot gas systems to intermittent pilot - Max capacity 270kBtuh Electrical ratings: 24 Vac | Frequency: 60 Hz | Flame failure response time (sec): 2.0 sec | PrePurge: 0 or 30 seconds | Ambient temperature range (C): -40 C to +74 C | Ambient temperature range (F): -40 F to +165 F | Ignition system type: Intermittent pilot | Ignition sequence: Continuous retry, after trial for ignition, pilot gas shuts off for 5 minutes, then another trial for pilot ignition takes place | Typical gas control: VR8204, VR8304 | Type of gas: Natural or LP | Flame sense: Single rod or two rods | Ignition source: Internal high voltage spark generator | Ignition trials to lockout: Continuous retry | Lockout timing: 15 or 90 seconds | Ignition trial time (sec): 15 or 90 seconds | Maximum valve load @ 24 Vac (Amps): 1A Pilot, 2A Main @ 24Vac | Typical ignition hardware: Q345, Q3451

HVAC 120 VAC Fuel Oil Igniter & Base Plate Kit Input voltage: 120 VAC, 50-60 Hz, 35 VA | Output voltage: 6kV RMS, 20kV peak | Output current: 35 mA RMS | Secondary mid-point ground | Ambient operating temperature: -40°F (-40°C) to 150°F (66°C) | Storage temperature: -40°F (-40°C) to 150°F (66°C) | Moisture: 5 to 95% Relative humidity

HVAC Igniter Flame Rod Sensor Assembly

HVAC Snap Disc Limit Control 135 - 175 Degrees F Range Open on Rise SPST | Flanged airstream mount | Adjustable set point | Automatic reset

HVAC Snap Disc Limit Control 175 - 215 Degrees F Range Open on Rise SPST | Flanged airstream mount | Adjustable set point | Automatic reset

HVAC Rollout Limit Switch L300F M/R Resettable

HVAC Hot Surface Pilot Burner Assembly & Flame Sensor

3/4" NPT Intermittent Hot Surface Pilot Ignition SmartValve Mounting: 0 to 90 degrees in any direction from the upright position of the gas control knob, including vertically | Electrical ratings: 24 Vac | Frequency: 50 Hz / 60 Hz | Flame failure response time (sec): 1.6 sec @ 3 µA | PrePurge: 15 seconds | PostPurge: 30 seconds | Ambient temperature range (C): -40 C to +79 C | Ambient temperature range (F): -40 F to +175 F | Ignition system type: Intermittent hot surface pilot ignition | Ignition sequence: Intermittent pilot | Type of gas: Natural | Flame sense: HSI | Ignition source: Pilot | Ignition trials to lockout: Continuous retry | Ignition trial time (sec): 90 sec | Typical ignition hardware: Q3450; Q3480 | Body pattern: Straight-through | Opening characteristics: Standard | Pressure regulator setting (psi): 3.5 in. WC | Pressure regulator setting (kPa): 0.87 kPa | Pressure ratings (psi): 1/2 psi | Pressure ratings (kPa): 3.5 kPa | Inlet/Outlet size (in.): 3/4 in. NPT x 3/4 in. NPT. | Pilot gas outlet: Yes | Capacity (ft³/hr): Maximum at 1 in. P.D.--300 ft³/hr; Maximum--415 ft³/hr; Minimum--30 ft³/hr | Capacity (m³/hr): Maximum at 1 in. P.D.--8.5 m³/hr; Maximum--11.8 m³/hr; Minimum--0.8 m³/hr | Pressure tapping: 1/8 in. - NPT

HVAC Defrost Relay 1 SPST-NO (Normally Open), 2 DPDT Coil frequency (Hz): 50/60 | Coil voltage: 24VAC | Contact bias: NO: 7-4,8-5; NC: 7:1, 8:2, 9-3 | Horsepower rating at 120V (HP): 1/3 | Horsepower rating at 277V (HP): 1/2 | Horsepower rating at 600V (HP): 3/4 | Number of DPDT contacts: 2 | Number of SPST-NO contacts: 1 | Terminal connections: 3/16 Inch quick connects

HVAC Defrost Control Board Amps: 1 | Contact type: Screws | Control volts: 30 AC | Defrost time max (minutes): 10

HVAC Defrost Sensor Thermistor Open-on-Rise 3/8-Inch L68-30F 80 Length
